CMB-37C


Fanless barebone system support  Intel® Core™  i7/ i5 / i3 , Celeron 2002E Mobile processor

-

Overview

-

Features

- Product Image
- Ordering Guide
- Datasheet
  - User's Manual

Overview



COMMELL's CMB-37C is a high-performance Fanless barebone systems which support 4th generation Intel® Core™  i7 / i5 / i3 , Celeron2002E Mobile processor. CMB-37C is suitable for industrial application like industrial  control and automation, retail, gaming, print imaging .......

BackToTop

Features

dh
Form Factor  Fanless system
Construction  Heavy-Duty steel
3.5" Board / CPU

 Inside Motherboard : LE-37C

 Support CPU : 4th generation Intel® Core™  i7 / i5 / i3 , Celeron  2002E mobile processor

Drive Bay

 Internal  1 x 2.5" HDD space

Motherboard Extensive slot

 1 x SIM Socket

 1 x CFAST

Front Panel

 Power On / Off switch

 Reset switch

 LED for Power On/Off and HDD activity

 2 x USB 2.0

Rear Side I/O

 1 x DC jack

 1 x Audio

 1 x Display port

 1 x DVI

 1 x RS232

 2 x USB 3.0

 1 x RJ-45 Intel® Giga LAN

 1 x Antenna

Environment  Operating Temperature: 0 ~ 40ºC
Power supply  9~24V DC input
Dimension  195 x 110 x 80 mm

BackToTop

Ordering Guide



CMB-37C

Barebone with LE-37C 9~24V DC ipput

Processor

Intel® Core™  i7-4700QE / i5-4402E / i3-4102E , Celeron 2002E mobile processor

Memory

DDR3L 1333/1600 SO-DIMM for 1.0 / 2.0 / 4.0 / 8.0 GB
